NetStreams Panorama System Installation Guide
4-4
All specifications subject to change without notification. All rights reserved. Copyright © 2006 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 7872
installation with a Musica MU5066KP. For more detail on the ports on the rear panel
of the Panorama, see
Figure 4-2
Integrating PAN6400 VDC with Musica MU5066ADC in mirrored mode
To integrate PAN6400 VDC with Musica MU5066ADC in mirrored mode, complete
the following steps:
1.
Ensure power is off to all devices.
Legend
IR Emitter and
null modem
CAT5
Component
Coaxial audio
Speaker and
analog audio
Power and
speaker
Display
PANVP500
Back
Back
Front
Front
PANVP500
PAN6400 (1)
PAN6400 (2)
IR Emitter
Source
5.1 or 7.1 channel
speaker outputs
w
e
r
t
y
u
i
o
a
s
d
f
g
h
Musica Keypad
Front
Back
j
