Profile Series v.G1 Exit Device
Copyright © 2006, 2008, Sargent Manufacturing Company
, an A
SSA ABL
O
Y
Group company
. All rights reserved.
Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
ITEM
PART No.
DESCRIPTION
REQ’D
1
52-2839
Outside Escutcheon (Prox Only) Assembly (G1-PA, G1-TA)
1
1
52-2838
Outside Escutcheon (Keypad/Prox) Assembly (LK, G1-LU, G1-PK, G1-TU, G1-TP)
1
52-2432
Keypad/Proximity Bezel Assembly w/ Harness (LK)
1
52-2704
Key Pad and Proximity Assembly (LK, G1-LU, G1-PK)
1
52-2706
Proximity Assembly (G1-PA, G1-TA)
1
68-1397
Outside Escutcheon Housing Only
1
52-0176
Outside Escutcheon End Cap Only
1
2
52-2460
Inside Escutcheon Assembly with 100 User Controller (LK)
1
2
52-2833
Inside Escutcheon Assembly with 2000 User Controller (G1-LU)
1
2
52-2834
Inside Escutcheon Assembly with Prox/Key Pad Controller (G1-PA, G1-PK)
1
52-2836
Inside Escutcheon Assembly (Keypad Only)
with RF Technology Controller (G1-TU)
52-2835
Inside Escutcheon Assembly (Keypad/Prox or Prox Only)
with RF Technology Controller (G1-TA, G1-TP)
68-1396
Inside Escutcheon Housing Only
1
52-0175
Inside Escutcheon End Cap Only
1
52-2441
Enclosure (LK) Assembly
1
52-2783
Enclosure (G1-LU) Assembly
1
52-2784
Key Pad/Proximity Only Controller (G1-PA, G1-PK) Assembly
1
52-2786
2000 User (Keypad/Prox or Prox Only) Controller Assembly (G1-TA, G1-TP)
52-2785
2000 User (Keypad Only) Controller Assembly (G1-TU)
01-0803
Battery Alkaline (“AA” Cell)
6
3
52-0170
Battery Cover
1
52-2509
Battery Cover – RF Technology (G1-TU,G1-TP, G1-TA)
4
01-1212
Security Screw
1
5
01-0297
Security Tool
1
6
52-0033
Fire Stop Plate
1
7
01-1500
Fire Stop Screws #8 x 1/2” Type “AB” Phillips Pan Head Self Tap
2
9
52-0253
Battery Keeper
1
52-0344
Battery Keeper – RF Technology (G1-TU, G1-TP, G1-TA)
10
52-2425
Screw Pack (Includes item numbers 5, 6, 7, 15)
1
11
Consult Factory
Motorized ET Lever Trim
1
12
Consult Factory
Motor and Harness Assembly
1
13
01-4451
ET Through-bolts
2
15
77-0685
Escutcheon Through-bolts
2
16
68-2172
Center Case Assembly LHRB (Standard and 12-)
1
16
68-2173
Center Case Assembly RHRB (Standard and 12-)
1
17
99-2401
Mortise Lock LHRB
1
17
99-2402
Mortise Lock RHRB
1
18
68-0407
Chassis Cover
1
19
97-0052
Chassis Cover Screws
4
