26
5. After all leading and plastic residues have been
removed, run a clean, dry patch through the bore.
Follow this with a final, lightly oiled patch.
6. Inspect the barrel and chamber to be certain no
patches have inadvertently been left in them. Remove
any that remain.
7. Reassemble the shotgun and wipe all exposed metal
surfaces with an oiled cloth making sure to wipe away
all finger marks where moisture could accumulate.
Any dried oil in the receiver area should also
be removed.
8. Lightly oil your firearm at the points described
on page 10. Regular, light oiling is extremely
important to the durability and reliable operation
of your shotgun.
FIGURE 12
Trigger Group
Barrel
Firing Pin Spring Firing Pin
Slide Arms
Forearm Trigger Group Pin
Barrel Bracket
Bolt
Three-Shot
Adapter (Plug)
Magazine Three-shot
Adapter (Plug)
Magazine Tube
Choke Tube
Magazine Cap
Bolt Slide
Magazine Spring
Magazine Spring Retainer
Receiver
