i nstAllinG the t hree -s hot A DAptor (p luG )
If you need to install the magazine three-shot adapter
(plug) to limit your shotgun magazine to two shells
again perform the following operation:
1. Unscrew the magazine cap and remove it.
2. Using your index finger or a large blade-type
screwdriver, press the magazine spring retainer
into the magazine approximately 1" and rotate it
¼ turn (Figure 7).
3. The magazine spring retainer is under pressure
from the magazine spring, keep the magazine spring
under control and carefully remove the retainer.
Place the magazine three-shot adapter (plug) on
top of the magazine spring and replace the magazine
spring retainer.
4. Align the full-length grooves in the magazine spring
retainer with the protrusions inside the magazine tube,
found at the six and nine o'clock positions.
5. Compress the magazine spring and magazine
three-shot adapter back into the magazine tube.
6. Replace the magazine spring retainer by pushing
it into the magazine tube approximately 1" and
rotating it ¼ turn to lock it in place. Make sure
the magazine spring retainer.
7. Install the magazine cap.
l oADinG
when loading your shotgun always KeeP the
MuZZle Pointed in a saFe direCtion, always PlaCe
the “saFety” in the on saFe Position and KeeP
your Fingers away FroM the trigger. Failure to
Follow these warnings Could result in serious
injury or death.
16
FIGURE 9
Position the shell fully forward in the magazine.
