376826

Cover - Control Box Assembly

1

AB

376826-1

Cover - Control Box Assembly

1

CD

1

376782-1

. Cover - Control Box

1

AB

376782-2

. Cover - Control Box

1

CD

2

Deleted

3

204036

. Label - Precautionary

1

All

376783B

Box - Control Assembly

1

AB

376783B-1

Box - Control Assembly

1

CD

4

405535-2

. Support - P.C. Board

4

All

5

376807C

. Board - P.C., Motor Control

1

All

6

401937-2

. Block - Terminal, 20 Amp, 8 Station

1

All

7

407146

. Label - Terminal Block

1

All

8

403704-1

. Switch - Rocker, ON/OFF

1

All

9

Deleted

10

406926-3

. Potentiometer - 10K, 2 W

1

All

11

40209

. Strip - Weather, 1/16 x 1/2

68-1/4" All

12

40207

. Strip - Weather, 1/16 x 1/4

15-3/4" All

13

376718

. Plate - Cover

2

AB

376718-1

. Plate - Cover

2

CD

14

Deleted

15

406806

. Knob - Control

1

AB

406806-3

. Knob - Control

1

CD

16

408246-1

. Clip - Nylon

7

All

17

403091-4

. Plug - Hole, Plastic

1

All

18

402037-3

. Grommet

1

All

19

. Deleted

20

403091-2

. Plug - Hole, Plastic

2

All

21

405576-1

. Bushing - Terminal

1

All

22

376711B-1

. Wrapper - Control Box

1

AB

376711B-2

. Wrapper - Control Box

1

CD

23

W-10051-2

. Clamp - Wire Plastic

1

All

24

409838

. Grommet - Mtg.

4

All

25

409837

. Spacer - Nylon

4

All

26

371635

. Adapter - Gas R.H.

1

All

27

408242-1

. Fuseholder

2

All

2

28

401972-5

. Fuse - Slo-Blow, 7 Amp

1

All

—

Not Illustrated

Item

Part

Description

Qty Application

No

Number

per

Code

Assy

Parts List for Figure 5-2

430429-249

Troy, Ohio 45373

PARTS LIST

November 2, 1999 Revised

5-5
