PARTS LISTS 6-2 Manual 0-2696
6.03 System Replacement
Includes the following components: Power Supply with Work Cable and Clamp, Torch and Leads (as ordered),
Coolant, Torch Spare Parts Kit, Operating Manual.
Qty Description Catalog #
PAK Master 150XL 208/230V/460V Units:
With PCH 70° Hand Torch
1 25 ft (7.6 m) Lead Length 1-1570-2
1 50 ft (15.2 m) Lead Length 1-1571-2
With PCH 90° Hand Torch
1 25 ft (7.6 m) Lead Length 1-1590-2
1 50 ft (15.2 m) Lead Length 1-1591-2
With PCM Machine Torch (Unshielded Leads & Remote Pendant)
1 25 ft (7.6 m) Lead Length 1-1580-2
1 50 ft (15.2 m) Lead Length 1-1581-2
With PCM Machine Torch (Shielded Leads & CNC Cable)
1 25 ft (7.6 m) Lead Length 1-1582-2
1 50 ft (15.2 m) Lead Length 1-1583-2
PAK Master 150XL 220/380-415V Units:
With PCH 70° Hand Torch
1 25 ft (7.6 m) Lead Length 1-1570-3
1 50 ft (15.2 m) Lead Length 1-1571-3
With PCH 90° Hand Torch
1 25 ft (7.6 m) Lead Length 1-1590-3
1 50 ft (15.2 m) Lead Length 1-1591-3
With PCM Machine Torch (Unshielded Leads & Remote Pendant)
1 25 ft (7.6 m) Lead Length 1-1580-3
1 50 ft (15.2 m) Lead Length 1-1581-3
6.04 Power Supply Replacement
Includes: Power Supply with Work Cable and Clamp, Operating Manual, Coolant.
Qty Description Catalog #
PAK Master 150XL Power Supply
1 230V/460V 3-1500-2
1 220V/380V 3-1500-3
