SECTION 2: INTRODUCTION 10 Manual 0-2784
10. Overall Dimensions
Overall dimensions are with handle, lead wrap
bracket, and gas regulator/filter assembly installed.
19" (482 mm) High x 13" (330 mm) Wide x 24.75" (630
mm) Long
B. Gas Regulator/Filter Assembly
Specifications
The following specifications apply to the Gas Regulator/
Filter Assembly only:
1. Gas regulator maximum gauge pressure
160 PSI (11 bar)
2. Maximum input gas pressure
125 PSI (8.6 bar)
3. Filter
Coalescent type filter
2.04 Power Supply Options and
Accessories
NOTE
Refer to Section 6, Parts Lists, for part numbers
and ordering information.
The following options and accessories available for this
power supply, but must be ordered separately:
A. Dry Air Filter Kit
An optional in-line filter for use on compressed air
shop systems. highly effective at removing moisture
and particulate matter from the air stream to at least
0.85 microns.
B. Two Stage Air Line Filter
An alternative to the Dry Air filter, this optional two
stage air line filter is for use on compressed air shop
systems. Filters moisture and contaminants to 5.0 mi-
crons. This filter assembly is pre-assembled at the fac-
tory and need only be attached to the power supply.
C. High Pressure Regulators
High pressure regulators are available for air and ni-
trogen. The regulators are used to set the proper pres-
sure for the type gas being used.
NOTE
Regulators should not be installed with options A
or B above.
D. Smart Cart
Steel cart on easy rolling 10" pneumatic tires to pro-
vide maximum mobility for the power supply. Handle
is 3/4" tubing with hooks for storage of torch leads.
A tie down strap is also included.
E. Computer Control Cable (CNC)
NOTE
This accessory can be used only with the PCM-60
Torches.
The interface cable is available in two lengths, 25 ft
(7.6 m) and 50 ft (15.2 m). The cable is used to inter-
face the power supply with an auxiliary control de-
vice to provide OK-To-Move and ON/OFF signals.
F. Remote Hand Pendant Control
The remote hand pendant control is available with a 25
ft. (7.6 m) cable. An extension cable of 25 ft. (7.6 m) can
be added to the standard hand pendant control to pro-
duce a total length of 50 ft. (15.2 m).
G. Cutting Guide Kit
Easy add-on attachments to allow for straight line, circle,
or bevel cutting.
H. Standoff Cutting Guide
Simple, push-on guide attachment to allow for torch drag-
ging without risk of touching tip.
