Snow Detector & Melting Control 667
D 667
03/09
The Snow Detector & Melting Control 667 is a microprocessor-based control which operates a snow melting system. The control can
operate automatically when a Snow / Ice Sensor 090 is installed or the user can manually enable and / or disable the system. The
667 controls a variable speed injection pump to provide both boiler and slab protection. When the control is not in the Melting mode,
the system can either be shut down or it can be maintained at an idle temperature for faster response and improved safety. The 667
control includes a large Liquid Crystal Display (LCD) in order to view system status and operating information.
Additional features include:
• Temporary
Idle
• Slab protection for the snow melting system
• Boiler
protection
• Manual
Override
• Adjustable Warm Weather Shut Down (WWSD)
• Cold Weather Cut Out (CWCO)
• Remote display and adjustment capabilities
• Test sequence to ensure proper component operation
• Pump
exercising
• Viscosity
compensation
• CSA C US Certifi ed (approved to applicable UL standards)
3
Red
4
Blk
5
Blu
6
Yel
7
Brn/
Slab
Mix
Ret Sup
8
Boil
9
Com
10
tN2
11
Mix
12
Mix
13
Com
14
Out
15
Melt/Idle
Demand
Pmp 2
16 17
System
Boiler
18
21
Melting
22
23
25
Sys
P1
24
Power
L
N
Test
Snow Detector & Melting Control 667
Variable Speed Injection
Idle Demand
Signal wiring must be rated at least 300 V
Melt Demand
not testing
testing
testing paused
For maximum heat,
press and hold Test
button for 3 seconds.
Made in Canada by
tekmar Control Systems Ltd.
tektra 900-04
Power
115 V ± 10% 50/60 Hz 600 VA
Relays
230 V (ac) 5 A 1/3 hp
Var. Pump 230 V (ac) 2.4 A (FLA), 5A (LRA)
fuse T2.5 A 250V
Demand
20 to 260 V (ac) 2 VA
off
red
red
Do not apply power
19 20
Input
Outdoor
Sensor
Included
Input
Melt/Idle
Demand
Output
System
Pump
Output
System
Pump
Output
Variable Speed
Injection Pump
Input
115 V (ac)
Power
Supply
Input
Remote Display Module (RDM)
or
Remote Start / Stop Module
OR
Melt Demand
Idle Demand
WWSD
Minimum
Maximum
Water
Melting
Input
Snow/Ice Sensor
090 installed with
Sensor Socket
091 Optional
Input
Slab Sensor
Optional
or
Start
Menu
Item
Stop
Do not apply power
Output
Melt Relay
Output
Boiler
1
Var
2
Pwr
H2029C
Input
Universal
Sensor
Included
Input
Universal
Sensor
Included
Input
Universal
Sensor
Included
Meets Class B:
Canadian ICES
FCC Part 15
Dat
e Code
