364 View Menu (1 of 2)
Item Field
Access
Level
Description Range
Section LT
D
USER INS
T
AD
V
---, 35 to 100°F
(2 to 38°C)
D3
-58 to 167°F
(-50 to 75°C)
D3
---, 35 to 110°F
(2 to 43°C)
D3
---, -58 to 167°F
(-50 to 75°C)
D3
-58 to 167°F
(-50 to 75°C)
D3
STRT, STOP, IDLE,
EXT, 0:00 to 17:00
hr, ---, INF, WWSD,
CWCO
E1
---, -25 to 230°F
(-32 to 110°C)
D1
-31 to 266°F
(-35 to 130°C)
D1
-85 to 170°F
(-47 to 94°C)
E1
---, 35 to 110°F
(2 to 43°C)
B2
Current outdoor air temperature as measured by the out-
door sensor.
Target room air temperature. “---” denotes no heat is
required.
MIX 10K = INDR
Measured room air temperature at the indoor sensor.
MIX 10K = INDR
This is the signal that is being received from a tekmar
Zone Control that is operating the mixing zones.
MIX 10K = ZOIN
Target slab temperature. “---” denotes no heat is
required.
DIP switch = Snow melting, MIX 10K = SLAB
Current slab sensor temperature.
MIX 10K = SLAB
Current operating status of the snow melting system.
DIP switch = Snow melting
Target mixed supply is the temperature the control is
currently trying to maintain at the mixing sensor.
Current mixed supply water temperature as measured
by the mixing sensor.
Current mixed ∆T. This is the current temperature differ-
ence between the mixed supply and the mixed return
sensors.
DIP switch = Snow Melting,
∆T MAX ≠ OFF
This is the signal that is being received from a tekmar
Zone Control that is operating the boiler zones.
-67 to 149°F
(-55 to 65°C)
