RAIDExpress 133 RAID USER MANUAL
91
How to Create Disk Array?
1. Create RAID 0
l Open RAID Manager.
l Change the control panel to “Create Disk Array”.
l Select “Array Type” as “RAID 0”.
l Check “Erase Partition” to erase partition table or uncheck “Erase
Partition ” not to erase partition table.
l Select “Stripe Size”. Default is 64 KB.
l Select at least two disks.
l Click “Create”.
2. Create RAID 1
l Open RAID Manager.
l Change the control panel to “Create Disks Array”.
l Select “Array Type” as “RAID 1”.
l Check “Erase Partition” to erase partition table or uncheck “Erase
Partition ” not to erase partition table. If there is an Array of RAID 1 or RAID
0+1, “Erase Partition” can’t be modified.
l If “Erase Partition” is unchecked, the “Source” must be assigned.
l Select exactly two disks (These two disks must be “primary master and
secondary master ” or “primary slave and secondary slave”).
l Click “Create”.
RAIDExpress 133 RAID USER MANUAL
92
3. Create RAID 0+1
l Open RAID Manager.
l Change the control panel to “Create Disks Array”.
l Select “Array Type” as “RAID 0+1”.
l Check “Erase Partition” to erase partition table or uncheck “Erase
Partition ” not to erase partition table. If there is an Array of RAID 1 or RAID
0+1, “Erase Partition” can’t be modified.
l If “Erase Partition” is unchecked, the “Source” must be assigned.
l Select exactly four disks.
l Click “Create”.
4. Create JBOD
l Open RAID Manager.
l Change the control panel to “Create Disk Array”.
l Select “Array Type” as “JBOD”.
l Select at least two disks.
l Click “Create”.
