RAIDExpress 133 RAID USER MANUAL
79
Functions Description
1. Starting
RAID Manager will be executed automatically when Microsoft Windows is booted. A
small icon, “ ”, will show in the system tray at the right bottom corner to indicate
RAID Manager is active.
Open RAID Manager
Double click on the small icon in the system tray to open the RAID Manager control
panel.
Click the right button on the small icon to open the menu then choose “Open”.
The system information will be presented in the beginning when the RAID Manager
control panel is opened. Please read the next section System Information for more
detail about system information.
Close RAID Manager
Click “Close” to close RAID Manager. The RAID Manager will be minimized to the
system tray at the right bottom corner but will not exit.
Terminate RAID Manager
Right click the small icon, and choose “Exit” to terminate RAID Manager.
Note: Click the “Start Menu” at the left bottom on the RAID Manager control
panel to choose RAID functions.
If more than one adapter exists, click the “RAID Adapter” at the right bottom to
RAIDExpress 133 RAID USER MANUAL
80
choose RAID Adapter.
Alert LED, at the right bottom, is used to indicate the whole system situation.
GREEN: Normal.
RED: If the configuration error of any array occurs.
BLINKING: If there is any array in rebuilding process.
