25 E-flite Piper Pawnee ARF Assembly Manual
Rudder and Elevator Installation
Required Parts
Fuselage Wing
Wing fairing 8-32 x 1-inch machine screw (2)
#8 washer (2) Stabilizer
Elevator (2) CA hinge (6)
Required Tools and Adhesives
Hobby knife Felt-tipped pen
Ruler T-pins
Thin CA Rotary tool
Drill bit: 1/16-inch (1.5mm) Square
30-minute epoxy Phillips screwdriver: #2
Medium CA Paper towel
Rubbing alcohol
 1. Attach the wing using two 8-32 x 1-inch machine
screws, two #8 washers and a #2 Phillips screwdriver.
 2. Use medium CA to glue the wing fairing to the
bottom of the wing. Use care not to glue the wing
to the fuselage.
 3. Measure and mark a center line on one side of the
stabilizer. This will help in the alignment.
