MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide

71

_K==oÉãçíÉ=`зенкзд=mêçíçÅçä

MatrixPRO Remote Commands

q^hb=Éå

Description: Cancel / Route all pending video/audio routes.

Parameters:

en

Mode; [0|1], Cancel all pending|Route all pending.

S

Example: TAKE 1 (Activates all pending video routes.)

rkls

Description: Saves the system parameters to non-volatile RAM. The system
parameters stored are the current output/input routes, grouping information, IP
setting and serial port configuration parameters. Upon power up, the system
configures itself according the parameters stored in non-volatile RAM.

Parameters: None

S

Example: UNOV (System parameters are saved to non-volatile RAM.)

Note

Issuing the parameter 0 is the equivalent of pressing the
CANCEL button on the front panel. 1 is the equivalent of
pressing the TAKE button on the front panel.
