56
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
^K==péÉÅáÑáÅ~нбзел
SDI Specifications
paf=péÉÅáÑáÅ~нбзел=
The table below lists MatrixPRO SDI specifications.
Table A-1. MatrixPRO SDI Specifications
Parameter
Detail
Specification
Video Input
Number/signal type
16 Unbalanced serial data
Connectors
16 BNCs
Signal Type
SMPTE 259M compliant
Signal Speeds
143, 177, 270, 360 Mbps
Impedance
75 ohms
Return loss
-15dB @ 270 MHz
Maximum Cable Length
350m at 270Mbps using Belden 1694A cable
Video Output
Number/signal type
16 Unbalanced serial data
Connectors
16 BNCs
Signal Type
SMPTE 259M compliant
Impedance
75 ohms
Return loss
-15dB @ 270 MHz
Amplitude
800mV +/-10%
Output Jitter with
reclocker enabled (max)
0.2 U.I (Alignment), 1.0 U.I (Timing) per SMPTE specifications
Switching type
Vertical interval per SMPTE specs - input channel 1 reference
