MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide

27

3. Operation

Menu Structure

oЙЕ~дд=mêÉëÉíë=jÉåì

From the Main Menu, select Recall to display the Recall Presets Menu, as illustrated
below.

Figure 3-17. MatrixPRO Recall Presets Menu

There are eight video signal configuration presets that can be recalled.

„

To recall presets:

1. Press SEL to enter the edit mode (#).

2. Use the selector knob to scroll to the desired file number.

3. Press SEL once more to recall the entire machine state from the selected file.

4. Press ESC to exit the edit routine.

5. Press ESC key once more to return to the Main Menu.

RECALL

> File

1
