20 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
3. Operation
Menu Structure
pÉíìé=jÉåì
From the Main Menu, select Setup to display the Setup Menu.
Figure 3-5. MatrixPRO Setup Menu
Each menu is explained in detail below:
• System Menu
• Factory Reset Menu
• Tech Support Menu
póëíÉã=jÉåì
From the Setup Menu, select System to display the System Menu
Figure 3-6. MatrixPRO System Menu
Each menu is explained in detail below:
• VFD Brightness Menu
• Serial Mode Menu
• RS-232 Settings Menu
• RS-485 Settings Menu
• IP Address
• System Save
• System Recall
SETUP
> System >>
Factory Reset >>
Tech Support >>
SYSTEM
> VFD Brightness +10
Serial Mode >>
RS-232 Settings >>
RS-485 Settings >>
IP Address >>
System Save >>
System Recall >>
