10
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
2. Hardware Installation
Rack-Mount Installation
o~ÅâJjçìåí=fåëí~дд~нбзе
MatrixPRO 16x and 8x Digital Router units are designed to be rack mounted.
Please note the following important points:
•
When rack mounting the unit, remember that maximum ambient operating
temperature for the unit is 40 degrees C.
•
Leave at least one inch of space front and rear to make sure that the airflow
through the fan and vent holes is not restricted.
•
When installing equipment into a rack, distribute the units evenly to prevent
hazardous conditions that may be created by uneven weight distribution.
•
Connect the unit only to a properly rated supply circuit.
•
Reliable Grounding (Earthing) of Rack-Mounted Equipment should be maintained.
