66

MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide

_K==oÉãçíÉ=`зенкзд=mêçíçÅçä

MatrixPRO Remote Commands

j~íêáñmol=pÉêá~д=`згг~еЗ=iáëíLaÉëÅêáéíáçå

ebim

Description: Displays a list of available commands on a terminal emulator such
as ProComm or Hyperterminal.

Parameters: None

S

Example: HELP (Returns the command list.)

`ib^o

Description: Clears all existing and pending video routes.

Parameters: None

S

Example: CLEAR (Clears all existing and pending video routes.)

`prjpq^q

Description: Displays firmware checksums and other information.

Parameters: None

S

Example: CSUMSTAT (Displays firmware checksums and other
information.)

cmil`h=Éå

Description: Lock / unlock the front panel from user input. Locking the front
panel results in the front panel not responding to user button presses.

Parameters: en -[0|1], Disable|Enable

Query: FPLOCK? Returns the current front panel lock status in the format: =en

S

Example: FPLOCK 1 (Locks the front panel from the user.)

d^aa=Цкй=змн=бе

Description: Add an output and/or input to the selected group index.

Parameters:

grp

Group number to add output; [1-16]

out

Output number to add; [1-16] / 101 if no output to add

in

Input number to add; [1-16] / 101 if no input to add

S

Examples:

GADD 1 4 2 (Add output 4 and input 2 to group 1.)

GADD 1 101 5 (Add input 5 to group 1.)

Note

The user cannot add output to more than one group index.
