MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide

4. GUI Installation and Operation

GUI Operation

drf=léÉê~нбзе

As with all Barco Folsom products, if the hardware is populated or functionality is enabled,
the control "keys" will be labelled in black. If channels of hardware are not populated, the
"key" labels will be grayed out.

S

Example: In the case of a 8x8 router, input channels 9 through 16, and
output channels 9 through 16 will be grayed-out.

The following topics are discussed in this section:

Video Switching Tab

Preset Save And Recall

Menu Bar

Labeling Tab

Grouping Tab

Sequencing Tab

Setup Tab

The "About" Tab
