SureCross™ DX80K Wireless Configured
FlexPower™ Kit
Analog Configuration (Default configuration)
For analog configuration, DIP switch 2 is in the OFF position. Analog configuration has analog IN 1 linked to switch power 1 (SP1) and is
programmable using switches four through eight. Analog input 2 uses the report rate and sample intervals listed in the table below. Discrete
inputs 1 and 2 are also active in this configuration and the input types are defined using switch 3. Two sinking discrete outputs are active for
this configuration.
Analog Configuration, Switch 2 OFF
DIP Switches
Descriptions
3
4
5
6
7
8
Discrete Sinking (NPN)
OFF*
Discrete Sourcing (PNP)
ON
Booster 10V (Analog IN 1)
OFF
Booster 15V (Analog IN 1)
ON*
Warm-up Time 10 milliseconds
OFF
Warm-up Time 500 milliseconds
ON*
Sample/Report Rate 1 second
OFF
OFF
OFF
Sample/Report Rate 2 seconds
OFF
OFF
ON
Sample/Report Rate 4 seconds
OFF
ON
OFF
Sample/Report Rate 16 seconds
OFF
ON
ON
Sample/Report Rate 64 seconds
ON
OFF
OFF
Sample/Report Rate 5 minutes
ON
OFF
ON
Host configured (override switches)
ON
ON
OFF
Sample/Report Rate 15 minutes
ON*
ON*
ON*
Analog IN 2, Discrete 1, and Discrete 2 are not powered from switched power terminals. In this configuration, SP2 is disabled. If you need SP2, contact the factory.
Discrete Configuration
The discrete configuration matches the switch power outputs (SP1, SP2) with the discrete inputs. The analog inputs are disabled. The discrete
configuration is selected when switch 2 is in the ON position. Two sinking discrete outputs are active for this configuration.
Discrete Configuration, Switch 2 ON
DIP Switches
Descriptions
3
4
5
6
7
8
Discrete Sinking (NPN)
OFF
Discrete Sourcing (PNP)
ON
Booster 5V
OFF
Booster 10V
ON
Warm-up Time 4 milliseconds
OFF
Warm-up Time 10 milliseconds
ON
Sample/Report Rate 62.5 milliseconds
OFF
OFF
OFF
Sample/Report Rate 125 milliseconds
OFF
OFF
ON
Sample/Report Rate 250 milliseconds
OFF
ON
OFF
Sample/Report Rate 500 milliseconds
OFF
ON
ON
Sample/Report Rate 1 second
ON
OFF
OFF
Sample/Report Rate 2 seconds
ON
OFF
ON
Host configured (override switches)
ON
ON
OFF
Sample/Report Rate 16 seconds
ON
ON
ON
Notes: Discrete IN 1 uses switched power 1 (SP1). Discrete IN 2 uses switched power 2 (SP2). Analog inputs 1 and 2 are disabled.
