5.4 Configuring external devices ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
34 ￭￭￭￭￭￭￭￭ 865 Dosimat plus
Directory structure on the USB stick
A directory with the instrument number is generated on the USB stick. The
structure within the directory appears as follows:
Figure 16 Directory structure on the USB stick
Backup All of the files of the backup are stored in this
directory. The directory will be created the first
time a backup is created.
Files Exported methods will be stored in this directory.
The directory will be created the first time a
method is exported.
Only methods being located in this directory can
be imported.
5.4 Configuring external devices
Menu ▶ System ▶ External devices
PC/LIMS report
Specification of the memory location for the PC/LIMS report. The PC/LIMS
report is a machine-readable report with all of the data important for a
determination. It can be saved as follows:
￭ as a TXT file on a USB stick.
￭ to a LIMS via an RS-232 interface. The 6.2148.030 RS-232/USB Box is
required for this purpose.
Selection COM2 | USB Stick
Default value USB Stick
COM2
The report is sent via the serial COM2 interface. The interface parame-
ters set in the dialog COM2 settings are used (see "Editing the COM2
settings", page 36).
USB Stick
The report will be saved as a TXT file on the USB stick in the folder
pc_lims_report.
Printer
If a printer is connected, then the printer type needs to be defined here in
order for the reports to be printed out correctly.
