Metrohm 865 Dosimat plus - Manual (Page 21)

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
865 Dosimat plus ￭￭￭￭￭￭￭￭ 11
The parameters for the RS-232 interface on the instrument must match
those on the balance (see "Editing the COM1 settings", page 35). Addi-
tionally consult the user manual of the balance.
3.5 Connecting a keyboard, printer and other USB devi-
ces
The 865 Dosimat plus has a USB (OTG) connector. Use the provided
6.2151.100 adapter USB MINI (OTG) - USB A for connecting USB devices
as e.g. printers, keyboards or USB sticks, see the following figure.
6.2151.100
Figure 7 Connecting USB devices
Caution
Switch the instrument off before connecting or disconnecting a USB
device or a USB stick.
The 865 Dosimat plus can only recognize the device immediately after
switching on.
The following devices can be operated directly on the USB connector
with the 6.2151.100 adapter:
￭ USB sticks (for the backup or storing of methods)
￭ 6.2147.000 numerical USB keypad
￭ 6.2148.030 RS-232/USB Box (for connecting balances or for the
RS-232 remote control)
￭ USB hub (with or without an own power supply)
The 6.2147.000 numerical USB keypad serves for comfortable numer-
ical input and for navigating in the dialog. In addition, it provides two USB
connectors. Connect additional USB devices to the keypad.
