3.3 Setting lift positions
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
74 ￭￭￭￭￭￭￭￭
815 Robotic Soliprep
This applies to the following positions:
Variable name Position in mm
take needle 180
aspirate sample 150
take filter 167
put filter 127
waste tool 33
aspirate filtered 138
needle in vial 128
aspirate pressure 115
To find the method variables, proceed as follows:
1 Click on the Method symbol in the tiamo™ sidebar.
2 Click on Open... in the File menu.
3 Select 815 Robotic Flexible Soliprep - standard method from
the list of available methods and click on [Open].
4 Double-click on the START - Main track symbol.
5 Click on the Method variables tab.
The values of the variables can be changed in this table as necessary.
Opening the manual control
1 Click on the hand symbol in the tiamo™ sidebar.
2 In the left-hand window, click on the Tower 1 item under 815_1
(815 Robotic …) and then select the Move tab.
