Metrohm 815 Robotic Soliprep - Manual (Page 123)

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4 Robotic Filtration Soliprep 2.815.3110
815 Robotic Soliprep
￭￭￭￭￭￭￭￭ 115
6.2037.070
6.1432.320
The lid with the hole belongs on the waste beaker (position 103) into
which a preliminary filtrate of the sample solution is to be disposed of
when membrane filters are used. The filter can be placed on the hole in
the lid with the robotic arm and pressure can be applied to force the sam-
ple solution through the filter.
The sample beaker can be defined as a special beaker for the purpose of
dabbing off the Polytron aggregate if required.
4.2 Defining rack positions
1 In tiamo, select Configuration.
2 Double-click on the device name 815_1.
3 Switch over to the tab Rack and click on [Rack data] to open the
rack parameter settings.
4 Select the tab Special beaker.
