2.2 Setting lift positions
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
36 ￭￭￭￭￭￭￭￭
815 Robotic Soliprep
6 Click on the associated [Assign] button. Observe the illustration
above.
7 Switch back to the Move tab.
Lift position for the Polytron
1 In the manual control in the left-hand window, click on the Tower 2
item under 815_1 (815 Robotic …) and then select the Move tab.
2 Under Rack position, select the Target position = 1 and click on
[Start].
3 Move the lift to the Target position = Work position.
The Polytron must be at a suitable height for sample dispersion. Cor-
rect the lift position if necessary.
4 If the position has had to be corrected, switch to the Assign posi-
tion tab.
5 Under Lift position, select the Work position for = Tower, if this
is not yet selected.
6 Click on the associated [Assign] button.
7 Switch back to the Move tab.
Lift position for the washing station
These settings apply to tower 2.
1 Under Robotic arm position, select Target position = External
1 and click on [Start].
2 If the Polytron is not positioned over the washing station, correct the
position of the robotic arm using the arrow keys [Arrow left] and
[Arrow right] as necessary.
3 If the position has had to be corrected, switch to the Assign posi-
tion tab.
