2.3 Flow diagram
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
12 ￭￭￭￭￭￭￭￭
850 Professional IC –Anion – MCS – Prep 3
3 High pressure pump
See Chapter 2.10. 4 Purge valve
See Chapter 2.10.1.
5 Inline filter
See Chapter 2.11. 6 Pulsation damper
See Chapter 2.12.
7 Injection valve
See Chapter 2.16. 8 Separation column
See Chapter 2.23.
When a guard column (see Chapter 2.22,
page 66) is used, it is installed between
injection valve and separation column.
9 MSM
See Chapter 2.18. 10 MCS
See Chapter 2.19.
11 Detector
See Chapter 2.20.
12 Eluent output
Connection to the waste container.
13 Sample input
Connection to the sample vessel (single ves-
sel or sample changer).
14 Sample degasser
See Chapter 2.13. Use optional.
15 Sample Preparation Module (SPM)
For sample preparation. See Chapter 2.14.
16 Sample output
17 Peristaltic pump
See Chapter 2.15.
18 Regeneration solution input
Connection to the regeneration solution
bottle.
19 Regeneration solution output
Connection to the waste container.
20 Rinsing solution input
Connection to the rinsing solution bottle.
21 Rinsing solution output
Connection to the waste container.
22 Peristaltic pump
For sample preparation. See Chapter 2.15.
23 Regeneration solution input
Connection to the regeneration solution
bottle.
24 Regeneration solution output
Connection to the waste container.
25 Rinsing solution input
Connection to the rinsing solution bottle.
26 Rinsing solution output
Connection to the waste container.
