Sensor Docking Station
Introduction
The Bully Dog Sensor Docking Station connects aftermarket
sensors to your GT or WatchDog. The Sensor Docking Station
does not work with monitoring or tuning products that are not
manufactured by Bully Dog. See page 9 for information
about the types of sensors that will work with the Sensor
Docking station.
IMPORTANT NOTE: To work properly with the Sensor Docking Station,
all GTs and WatchDogs must be updated to the following software
version (or newer):
Light Duty: 1.1.4.0 Heavy Duty: 1.0.3.6
Table of Contents
Parts and Tools ....................................................1-8
Docking Ports and Sensors .................................9-10
Pyrometer Installation ..........................................11-14
Sensor Docking Station Installation .....................14-20
Status Check ........................................................21
Sensor Wiring, Setup and Calibration ..................22-37
Pyrometer ....................................................................... 23-26
Analog Sensor ................................................................ 27-28
Frequency Sensor ........................................................... 29-30
Temperature Sensor ....................................................... 32
O
2
Sensor ....................................................................... 35-36
Purchasing Compatible Sensors ..................................... 37
More Information ..................................................38
Installing a pyrometer or O
2
sensor can be difficult because
the exhaust manifold or post-turbo exhaust downpipe
must be drilled and tapped. Welding may also be required.
Bully Dog recommends that you utilize professional
assistance if you have not had experience with these
procedures.
