INSTALLATION
INSTRUCTIONS
1221Instructions 11-04-14.doc Page 3 of 5
Step 7: Insert the (4) 1/2” Flat Head T-10
Torx Screws through top of tray and into
FreedomCharge module.
Step 8: Install Non-Slip Freedom Charge Mat
to Wireless Charging Module. Place the 4
locator pins in corresponding holes.
Step 9: Trim Factory mat to template
provided.
Step 10: Install cut factory mat
Step 11: Drill ½” hole on driver side of
armrest bin
Step 12: Loosen console side trim
