INSTALLATION
INSTRUCTIONS
1240 Instructions 6-26-14.docx Page 1 of 4
2011 – 2014.5 Toyota Camry Qi Wireless Charging Kit
(Kit # FDMC-1240)
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit: Tools & Supplies Needed:
Qi Wireless Charging Module with
Camry Specific Substrate and Mat
Power Harness with 3 amp Fuse
4 – Pan Head Torx 3/8” Screws
These Instructions with Template
Removable Consumer Product Label
Plastic Trim Removal Tool
T-15 Torx Driver
Phillips Screwdriver
Center Punch/Scribe Tool
Power Drill
3/16’’ and 1/2” Drill Bits
Wire Ties
Soldering Iron & Solder
(Recommended)
Tape or Heat Shrink Electrical Tubing
*Note this product is designed to work with Qi compatible devices. Please confirm that
your device is Qi compatible before installation. Visit www.brandmotion.com for phone
compatibility guide.
Safety Precautions:
• Work in well ventilated area that is clear of obstructions.
• Secure vehicle with tire chucks in both front and rear of tires.
• Turn vehicle accessories OFF and ensure ignition key is in OFF position.
• Wear safety goggles and snug fitting clothes.
• Use tools only for their intended purpose and which are in good repair.
• Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions.
IMPORTANT: Do not place smart keys
within 6 inches of charging mat.
Vehicle may not detect key to start
vehicle. Do not place metal objects in
tray while charging.
