INSTALLATION INSTRUCTIONS
8531 Instructions 9-5-14.docx
Page 1 of 4
OEM Lip Mount CCD Camera Kit for 2011 – current Chrysler 300, Dodge
Charger, & Dodge Journey Factory Display Radios (CTP, RE2, RE4)
(Kit part number 9002-8531)
NOTE: Requires Chrysler/Dodge dealer to activate; see below
Applications: 2011 – current Chrysler 300
2011 – current Dodge Charger
2011 – current Dodge Journey
Please read thoroughly before starting installation and check that kit contents are complete.
Items Included in the Kit:
Tools & Supplies Needed:
Bubble bag containing:
Camera with Mount (in zip lock bag)
Camera Harness
Chassis Harness
Z-tec Corrosion Inhibitor (in a white bottle)
Zip lock bag containing:
12 Wire Ties
2 Rubber Well Nuts
2 Bolts
Gray 22-pin Connector
Zip lock bag containing:
These Instructions
Self-adhesive Camera Mount Template
Phillips Screwdriver
Delphi Terminal Removal Tool #12094429 or
Small Flat Watch Repair Screwdriver
10mm Socket
Center Punch
1/8”, 5/8” and 5/16” Drill Bits
Power Drill
File
Soldering Iron & Solder
(recommended)
or T-Taps
Heat Shrink Tubing
(recommended)
or Electrical Tape
Plastic Trim Removal Tool
Rubber Grommet or Silicone Caulk
(recommended)
Cotton Swab
Vehicle Service Manual
(If needed)
Safety Precautions:
• Work in well ventilated area that is clear of obstructions.
• Secure vehicle with tire chucks in both front and rear of tires.
• Turn vehicle accessories OFF and ensure ignition key is in OFF position.
• Wear safety goggles and snug fitting clothes.
• Use tools only for their intended purpose and which are in good repair.
• Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest full color
instructions, as well as an installation video, please visit www.brandmotion.com
IMPORTANT: Use of this camera with
the factory screen requires activation
by a Chrysler/Dodge dealer. See below
for Dealer Programming Instructions.
If possible, have the dealer “enable”
the camera option prior to installation.
