9510 Instructions 5-10-12
Tel
734-619-1250
3 of 3
Toll Free
877-276-6456
Fax
480-247-5999
Pin 3 If present in vehicle it MUST be extracted and isolated (see Low Speed LAN note above)
Pin 8 Use White wire from supplied harness and insert into connector, connect opposite end of wire to a good solid chassis
ground.
Pin 9 Use Brown wire from supplied harness and insert into connector, connect opposite end of wire to the reverse lead from
the tail light circuit.
Pin 13 Use Green wire from supplied harness and insert into connector, connect opposite end of wire to the Ignition circuit of
vehicle. 12v+ when key is turned ON & 14.4 or better when vehicle is running.
Video signal: Connect RCA to camera video output. (See camera requriements above).
Pin 6 Camera video input positive- Insert Red wire from supplied harness (the opossite end of wire is attached to the video
input RCA). Note: If lead exists in this cavity remove and isolate as it is not needed.
Pin 7 Camera video input negative- Insert Black wire from supplied harness (the opossite end of wire is attached to the video
input RCA). Note: If lead exists in this cavity remove and isolate as it is not needed.
Operation: Temporary Monitor Manual Shut Down:
If while in reverse you require to turn OFF the camera monitor simply press and release the POWER button on the mirror.
(Note: once reverse is disengaged the mirror will go back to normal operation and will turn ON next time reverse is engaged).
