Element Tables

The following tables are used to determine the part numbers of elements required based on line section, power, and
frequency ranges.

Table 1-6 should be used to determine which element table to use, based on the model.

Note: Table 1-7 through Table 1-18, page 27 are numbered consecutively for convenience. The table head-
ing corresponds to the table heading in the Bird catalog which is the common reference for element tables.

Table 1-6 Element Table Selection

7/8" Line Section

Note: The following tables are used to select elements for 7/8" line sections.

Table 1-7 Selection Table

Table 1-8 High Frequency Milliwatt Elements - Entire Table (8% FS)

Model

Line Section

Mount

Meter Scale

Line Section in

Inches

Front
Panel

External Watts

kilowatts

7/8

1

5/8

3

1/8

6

1/8

25/50/100 5/10/25 15/30/60 Element Table (2-)

3170B

7 to 12

3170B400

3 to 8

3171B

13

15

17

3171B020

14

16

18

Power

Range

(Watts)

Frequency

2 - 30

25- 60

50 - 125

100 - 250

200 - 500

400 - 1000

5

--

5A

5B

5C

5D

5E

10

--

10A

10B

10C

10D

10E

25

--

25A

25B

25C

25D

25E

50

50H

50A

50B

50C

50D

50E

100

100H

100A

100B

100C

100D

100E

250

250H

250A

250B

250C

250D

250E

500

500H

500A

500B

500C

500D

500E

1000

1000H

1000A

1000B

1000C

1000D

1000E

2500

2500H

5000

5000H

Power

Range

(milliwatts)

Frequency

950 -
1260

1250 -
1500

1500 -
1700

1700-
2200

2300 -
2400

2400 -
2500

2500 -
2600

100

430-82

430-209

430-210

430-178

430-211

430-182

--

250

--

--

--

430-1

430-239

430-240

430-241

500

--

430-259

--

430-95

--

430-159

--
