22

Replacement Parts List

Line Section Cable Assemblies

Meter Cable Assemblies

Note: Cables are terminated with ring terminals that fit 1/4” meter studs.

Qty

Description

Part Number

1
2

AC power fuse

115V, 5x20 mm, Slo-Blo, T630 mA
230V, 5x20 mm, Slo-Blo, T315 mA

5A2257-14
5A2257-11

1

DC power fuse, 3 AG, 1/2 A

5-721-2

1

Power cord, 115/230 VAC

4421-055

2

Cable assembly (Line Section)

3170-058-1

2

Meter cable assembly

3170B110

2

Meter

Models 3170B, 3170B400
Model 3171B
Model 3171B020

2150A015-1
2150A086-1
2150A093-1

1

Line section assembly
(Model 3170B and 3170B400 only)

4522-002-7

2

Bezel kit
(for all meters)

2150A015-2

Length

Part Number

14”

3170-058-1

6’

3170-058-6

15’

3170-058-2

25’

*

* Use if line section is 6-1/8”

3171-010

25’

3170-058-3

40’

3170-058-4

50’

3170-058-5

80’

3170-058-7

90’

3170-058-8

100’

3170-058-9

Length

Part Number

2’

3170B110

6’

3170B110-6

15’

3170B110-15

25’

3170B110-25

50’

3170B110-50
