6

Figure 4 Models 3171B and 3171B020

Remote Line Section

AC Receptacle

RF Output
Connector

RF Input
Connector

1/4”

(6mm)

18-5/32”

(461mm)

19”

(483mm)

2-1/4”

(57mm)

1-31/64”

(38mm)

5-7/32”

(133mm)

~

6-7/16”

(164mm)

RFL

FWD

Meters
