5

Figure 3 Models 3170B and 3170B400

Line Section

AC Receptacle

RF Input
Connector

RF Output
Connector

1/4”

(6mm)

18-5/32”

(461mm)

19”

(483mm)

2-1/4”

(57mm)

1-31/64”

(38mm)

5-7/32”

(133mm)

Meters

6-7/16”

(164mm)
