9.
LED Indications
on OLED side:
As used to from former devices of the Cockit Time Code family, the ACN-LS has a red and a
green flashing LED to display operation and battery status:
0 1 2 3 4 seconds:
●
● ● ● ● red
flashing in 1 second intervals: running, but not jammed or set.
●
● ● ● ● green
flashing in 1 second intervals: running, jammed or set manually.
This is the normal operation mode.
●
●● ●●
red
double flash every 2seconds: battery low, not jammed or set.
●
●● ●● green
double flash every 2seconds: battery low, jammed or set.
●
●●● ● ●●●
combination of not sync and low battery, not set or jammed.
●
●●● ● ●●●
combination of not sync and low battery, set or jammed.
●
●
●
●
●
●
●
●
●
●
alternating colors during firmware update.
on LED Display side:
●
● ● ● ● green
flashing in 1 second intervals: running, jammed or set manually
●
●
● ● ● ●
green
flashing in 1 second intervals with off-beat every 4 seconds
indicates LED offset.
In LTC-VARI the LED is
solid red
if no time code is present,
solid green
if time code
recognized.
10. Firmware Update
New features, improvement and fixes for the ACN-LS will be available for download from our
website:
The firmware update comes as a zipped package including the QT programming interface and
the firmware file, and a Mac DMG
Windows®: Unzip the programming files. Connect the ACN-LS to a computer running a
Microsoft Windows® operating system using a USB-A cable to Mini-USB B connector and run the
updater. Press the “UPDATE” button. Wait until the message “update successful” appears.
Apple® MAC-OS: extract the archive, mount the DMG and run the updater. Press “UPDATE” and wait until
the programming is finished.
Contact us for bug reports and suggestions through our contact form.
