Ambient ATHPD User Manual
Adaptor, Athpd, Mounting adaptor for the „tinymike“ (atm216)
The mounting adaptor (ATHPD) serves to adapt the
diameter of the
„TinyMike“
to camera's microphone
bracket.
One to two layers of the supplied foam rubber build up
the diameter. Start and end the foam rubber near the
slit. For most Sony cameras one layer, for most Panaso-
nic two layers are sufficient.
ADAPTOR
MADE IN GERMANY
© Ambient Recording GmbH 2013
www.ambient.de/en
ATHPD
When done, insert the cable through the barrel adaptor
and plug it into the microphone.
Then insert the
„TinyMike“
into the ATHPD.
Mounting Adaptor for the „TinyMike“ (ATM216)
