Ambient Lockit - ACL 204 - Manual (Page 9)

7 www.ambient.de
↓
ACN
↓ MODE
↓
OFF ↔ JAM ↔ C_JAM ↔ TX ↔ RX
↓ ↓
MODE↔CHNL↔ANT↔PWR↔SYNC MODE Back one level to mode select
↓ ↓
JAM Mode for remote jamming of ACL 204 CHNL Select ACN channel 11 to 26
↓ ↓
C-JAM Mode for continuous jam / autosync ANT Select antenna internal ↔ external
↓ ↓
TX / RX Mode to transmit external recrun TC PWR Select RF output power 8 to 18 dBm
Mode to receive free- or recrun TC ↓
SYNC Send sync broadcast: yes ↔ no
Start continuous jam: yes ↔ no (C-JAM)
(not available in TX / RX)
↓
EXIT
Return to main operation display
