36
Rockwell Automation Publication GMC-RM005B-EN-P - September 2013
Kinetix 3 Drive Systems
Kinetix 3 (200V-class) Drives with LDL-Series Linear Motors
This section provides system combination information for the Kinetix 3 drives when matched with LDL-Series ironless
linear motors. Included are power and feedback cable catalog numbers, system performance specifications, and the
optimum force/velocity curves.
LDL-Series Cable Combinations
For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Motor/Actuator Cables Overview beginning on
.
Motor-end connector kits are available for motor power/brake and feedback cables. Refer to Optional Drive Accessories on
.
Cable length xx is in meters. Refer to the Kinetix Motion Accessories Technical Data, publica
, for standard cable lengths.
LDL-Series Performance Specifications with Kinetix 3 (200V-class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with actuator at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Linear Motors
Motor Power Cable
Motor Feedback Cable
(1)
(1) Use 2071-TBMF breakout board on drive end (battery not required). Refer to Kinetix 3 Motor Feedback Example (Bulletin MPAS, LDAT-Series, LDC-Series, and LDL-Series) on
for more information.
LDL-N030120-DHT, LDL-N030240-DHT, LDL-N030240-EHT
2090-CPWM7DF-16AAxx (standard, non-flex)
2090-CPWM7DF-16AFxx (continuous-flex)
2090-XXNFMF-Sxx (standard, non-flex)
2090-CFBM7DF-CDAFxx (continuous-flex)
Sin/Cos or TTL Encoder Feedback
LDL-N050120-DHT, LDL-N050240-DHT, LDL-N050240-EHT,
LDL-N050360-DHT, LDL-N050360-EHT, LDL-N050480-DHT, LDL-N050480-EHT
LDL-N075480-DHT, LDL-N075480-EHT
LDL-T030120-DHT, LDL-T030240-DHT, LDL-T030240-EHT
LDL-T050120-DHT, LDL-T050240-DHT, LDL-T050240-EHT, LDL-T050360-DHT,
LDL-T050480-DHT, LDL-T050480-EHT
LDL-T075480-EHT, LDL-T075480-EHT
Linear Motor
Speed, max
m/s (ft/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Linear Motor
Rated Output
kW
Kinetix 3
200V-class Drives
LDL-N030120-DHT
10.0 (32.8)
3.0
63 (14)
9.9
209 (47)
0.31
2071-AP4
LDL-N030240-DHT
6.0
126 (28)
19.9
417 (94)
0.63
2071-AP8
LDL-N030240-EHT
3.0
9.9
2071-AP4
LDL-T030120-DHT
3.0
72 (16)
9.9
239 (54)
0.36
2071-AP4
LDL-T030240-DHT
6.0
144 (32)
19.9
479 (108)
0.72
2071-AP8
LDL-T030240-EHT
3.0
9.9
2071-AP4
