Kinetix 3 Drive Systems
Performance Specifications with Frame 150 Linear Thrusters
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Kinetix 3 (200V-class) Drives/LDAT-Series Integrated Linear Thruster Curves
Linear Thruster
Cat. No.
Velocity, max
230V AC
m/s
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Rated Output
230V AC
kW
Kinetix 3
200V-class Drives
LDAT-S152010-DBx
…
LDAT-S152090-DBx
1.8
5.3
643 (145)
19.5
1799 (404)
0.87
2071-AP8
LDAT-S152010-EBx
…
LDAT-S152090-EBx
0.9
2.7
9.8
1679 (377)
0.34
2071-AP4
LDAT-S153010-DBx
…
LDAT-S153090-DBx
1.8
8.0
978 (220)
29.1
2680 (602)
1.33
2071-A10
LDAT-S153010-EBx
…
LDAT-S153090-EBx
1.8
10.7
1306 (294)
39.1
3597 (809)
1.78
2071-AP4
LDAT-S154010-DBx
…
LDAT-S154090-DBx
0.9
5.3
19.5
3383 (761)
0.70
2071-A15
LDAT-S154010-EBx
…
LDAT-S154090-EBx
1.8
16.3
1997 (449)
59.4
5469 (1229)
2.71
2071-AP8
LDAT-S156010-EBx
…
LDAT-S156090-EBx
0.9
8.1
19.8
5110 (1149)
1.05
2071-A10
2071-AP8 and LDAT-S031040-DBx
Velocity (m/s)
Force
(N)
Force
(lb)
200
175
150
125
100
75
50
25
0
45.0
39.3
33.7
28.1
22.5
16.9
11.2
5.6
0
0
2
4
3
1
= Intermittent operating region
= Continuous operating region
