B ●
FactoryTalk Transaction Manager and Microsoft COM+ Objects
●
●
●
●
●
153
Defining the COM+ Data Object
The remote component must already be installed on the COM+ server before you
can define a FactoryTalk Transaction Manager COM+ data object. For more
information, refer to the “Installing the remote component” section in this appendix. If
you are on a client computer, the application proxy must already be installed. For
more information, refer to the “Setting up the remote client” section in this appendix.
1. Select Configuration > Checklist.
2. From the Configuration Checklist, make sure that all previous steps
have been completed (a yellow or green checkmark next to a step
designates that the step has been completed), then click Step 4.
3. From the COM+ Data Object Definition dialog box, enter a name for
the connector in the Connector Name field.
4. Enter a name for the data object in the Name field.
5. If the desired COM+ connection does not display, click (…) to define
one.
6. From the COM+ Connection Definition dialog box, select a connection
name from the drop-down list or enter it in the Connection Name field.
The User Name and Password fields are disabled because they are not supported in
the initial release of Microsoft COM+.
7. Select a COM+ server from the drop-down list. The COM+ applications
(or proxies) installed on the computer display in the COM+
Applications area.
8. Select a COM+ interface from the list, click Apply, then click Close to
return to the COM+ Data Object Definition dialog box.
9. Select a COM+ Method from the drop-down list. The method
parameters that can be included in the specified FactoryTalk
Transaction Manager data object display in the Parameters column.
