7. Complete the steps in order of listing:
a. Input Voltage
b. Motor Dat/Ramp
c. Motor Tests
d. Speed Limits
e. Speed Control
f. Strt/Stop/I/O
g. Done/Exit
The Start-up routine automates the process of entering values of selected
parameters by taking you to the next parameter after you accept a
parameter value. As each item in the list is completed, you are
automatically advanced to the next step.
Exiting Before Completing the Start-up Routines
To exit the Start-up routines, press the ABORT ‘soft key’. When you select Begin
Start Up
from the START UP folder menu again, you are prompted to either
continue or restart the Start-up routines. If you select Continue, you are returned
to the point at which you exited.
IMPORTANT Parameter values are saved as they are changed. Pressing the ABORT
‘soft key’ does not undo the changes to the Start-up routine.
