Chapter 6 Prepare the Kinetix 6000 Multi-axis Servo Drive System
Additional Resources
Resource
Description
Kinetix Motion Control Selection Guide,
publication
Provides details on motor and drive performance specifications.
Kinetix 6000 Multi-Axis Servo Drive Installation
Ma
Provides details on panel layout, and how to install and wire Kinetix 6000 drives and
components.
Kinetix 6000 Multi-Axis Servo Drive User
Ma
Provides details on how to integrate your Kinetix 6000 system with a CompactLogix
2094-M04SE SERCOS module, including how to start up, configure, and troubleshoot
the system.
Line Interface Module installation Instructions,
publication
Provides details on how to install, wire, and troubleshoot the line interface module.
System Design for Control of Electrical Noise,
Provides best practices on how to minimize noise in control panel while complying with
noise regulations.
Kinetix Accelerator Toolkit Quick Start,
Provides complete details and tools to help you quickly integrate a Kinetix Motion
system into your ControlLogix system.
Logix5000 Motion Modules User Manual,
publication
Provides details on how to setup and configure motion control using your 1768 SERCOS
module.
System Design for Control of Electrical Noise
Video, publication
Contact your local distributor for details on how obtain publication.
Kinetix Accelerator Toolkit CD,
Contact your local distributor for details on how to obtain CD. See appendix B for more
information.
