Publication IASIMP-QS003B-EN-P - October 2009 17
Parts List: Option 2, 1768-L43 and 1768-L45 Systems with DeviceNet
The table lists the parts for a 1768-L43 and 1768-L45 Systems with DeviceNet I/O, serial
connections, and a 200/230V Kinetix 6000 Multi-axis Servo Drive System.
Parts List: Option 2, 1768-L43 and 1768-L45 Systems with DeviceNet Network

Quantity Catalog Number Description
General Configuration
1 1768-L43 and 1768-L45 CompactLogix Controller
1 1768-PA3 CompactLogix Power Supply
1 1769-ECR Compact I/O Right End Cap/Terminator
1 1769-IF4 Compact 4 Channel Analog Current/Voltage Input Module
1 1769-IQ16 Compact 16 Point 24V dc Sinking/Sourcing Input Module
1 1769-IF4XOF2 Compact 8 Bit Resolution, High Speed 4 In/2 Out Analog Combination Module
1 1769-OF2 Compact 2 Channel Analog Current/Voltage Output Module
1 1769-OB16 (1) Compact 16 Point 24V dc Sourcing Output Module
1 1734-IB4 (2) POINT I/O 4 Sink Input Module
1 1734-OB4E (2) (3) POINT I/O 4 Protected Output Module
1
1734-OE2C
(2) POINT I/O 2 Current Output Analog Module
1 1734-TB Wiring Base w/ Removable IEC Screw Terminals (Quantity of 10)
1 1794-PS13 FLEX I/O 85-264V ac to 24V dc 1.3A Power Supply
1 20AB4P2A3AYNNNNN PowerFlex 70 Drive
1 2711P-B10C4D1 PanelView Plus 10 inch color keypad/touch terminal with EtherNet/IP and RS-232
1 1747-CP3 or 1756-CP3 RS-232 cable for connection between the 1768-L43 controller and personal computer
1 2711-NC13 RS-232 cable for connection between the PanelView Plus terminal and the 1768-L43
controller or personal computer
1 64-134 DIN rail (steel not aluminum), 1 m
DeviceNet Configuration
1 1769-SDN Compact DeviceNet Scanner
1 1734-ADN POINT I/O DeviceNet Adapter
1 20-COMM-D PowerFlex 70 DeviceNet Adapter
1 1606-XLDNET8 DeviceNet Power Supply
1 1485C-P1E75 KwikLink Flat Cable, 75 m
2 1485A-T1E4 KwikLink Terminator/Resistor
3 1485P-P1E4-R5 KwikLink Sealed Micro Connector
3 1485K-P1F5-C KwikLink QD Cordset Micro Right-Angle Male
1 1485T-P1E4-B1 KwikLink Power Tap Module
