52
Publication IASIMP-QS003B-EN-P - October 2009
Chapter 2 Prepare the Computer and Load Controller Firmware
Install Additional Software
•
If your network configuration includes a PanelView Plus terminal, install FactoryTalk
Machine Edition software and RSLinx Enterprise software from the FactoryTalk View
Machine Edition package.
•
If you are using a DeviceNet network, install RSNetWorx for DeviceNet software. Also
install the DeviceNet Tag Generator Tool under optional steps of the RSNetWorx for
DeviceNet install.
Additional Resources
Resource
Description
CompactLogix Controller Installation
Instructions
Provides other methods for loading firmware in the controller.
FactoryTalk Activation FAQ, publication
Provides answers to FactoryTalk Activation questions, including how the FactoryTalk
Activation differs from master disk activation.
ControlFlash Firmware Upgrade Kit, publication
Provides details regarding the installation of ControlFlash software and execution of
firmware upgrades.
