197 Publication IASIMP-QS003B-EN-P - October 2009 197
Appendix
A
Network Information
Use the tables in this appendix to record network information that you will reference throughout the quick
start.
Ethernet Addresses
Device Ethernet Address
(MAC) Assigned IP
Address Assigned
Subnet Mask IP Addresses
for quick start Subnet Mask
for quick start
Computer Not needed 192.168.1.116 255.255.255.0
1768-ENBT EtherNet/IP Module 192.168.1.107 255.255.255.0
1734-AENT POINT I/O Adapter 192.168.1.101 255.255.255.0
20-COMM-E, PowerFlex 70
EtherNet/IP Adapter 192.168.1.103 255.255.255.0
PanelView Plus Terminal Not needed 192.168.1.105 255.255.255.0
EtherNet/IP Device Information
For this EtherNet/IP Device Record this data
20-COMM-E, PowerFlex 70 EtherNet/IP Adapter Major Revision
1734-AENT POINT I/O Adapter Major Revision
DeviceNet Device Information
For this DeviceNet Device Record this data
1769-SDN Scanner Module Series Letter
Slot Number 1
Node Address 1
DeviceNet.dnt File name and Path
Firmware revision (major.minor)
20-COMM-D, PowerFlex 70
DeviceNet Adapter Node Address 13
1734-ADN POINT I/O Adapter Node Address 2
Kinetix 6000 Device Information
For this Kinetix 6000 Device Record this data
1768-M04SE SERCOS Module Node Address 01
