Chapter 2, Introduction, Before you begin – Rockwell Automation Direct Drive Technology Demonstration Machine User Manual
Page 15: What you need, Introduction before you begin what you need, Chapter

15
Publication PMC-QS002B-EN-P - October 2008
15
Chapter
2
Using the Direct Drive Technology
Demonstration Machine
Introduction
In this chapter, you will start the Direct Drive Technology
Demonstration Machine and learn how to control it using the hardware
buttons and the RSLogix Software application.
Before You Begin
Complete installation instruction in Chapter 1. Check that back door is
secured.
What You Need
The personal computer user names and passwords are on labels located
on the left side of the combination computer monitor chassis and listed
here:
User Name: Rockwell
Password: Rock1234
or
User Name: Administrator
Password: An0rad1
Topic
Page
Using Push Button Switches and Door Interlock to Run the Machine
