Rockwell Automation AADvance Controller Troubleshooting and Maintenance Manual User Manual
Page 4
iv
Document: 553634
(ICSTT-RM406F_EN_P) Issue: 089:
Troubleshooting and Maintenance Manual (AADvance
Controller)
Issue Record
Issue
Date
Comments
01
Dec 2008
First Issue
02
Feb2009
Update with official product titles
03
Apr 2009
Change title and add calibration procedures
04
Nov 2010
Add fuse replacement
05
Mar 2011
Release 1.2
06
Aug 2011
Update Release 1.2 version for TUV review comments
07
Apr 2012
Update Release 1.2 to add Analogue Output Module information
08
June 2012
Update for Release 1.3 & 1.3.1
09
June 2013
Update to add on-line update procedure
Notes and Symbols used in this manual
This symbol calls attention to items which "must" be considered and implemented
when designing and building an AADvance controller for use in a Safety
Instrumented Function (SIF). It appears extensively in the AADvance Safety Manual.
Note: Notes are used extensively to provide important information about the product.
