1-2 Document: 553634
(ICSTT-RM406F_EN_P) Issue: 089:
Troubleshooting and Maintenance Manual (AADvance
Controller)
Required Tools Standard AADvance
The installation and maintenance of the AADvance controller requires the following tools:
Standard Tools
 Screwdriver, flat 0.8 x 9.0mm (1/25 c 3/8 inch), for the module clamp screws and
blanking covers
 Screwdriver, cross head number 0, for battery cover on T9110 processor module
 screwdriver, flat 0.8 x 4.0mm (1/25 x 5/32 inch), for locking screws on extension
cables
 Torque screwdriver, flat 0.6 x 3.0 mm(1/40 x 1/8 inch, for dc power wiring
terminals
 Torque screwdriver, flat 0.4 x 2.0mm (1/64 x 5/64), for field wiring terminals
 2 x wrench, open end, 10mm, for ground stud nuts
 Allen key (hex wrench), 2.5mm, for plug and sockets assemblies used with
extension cables
Special Tool
 Long nosed pliers to remove the fuses on termination assemblies.
Required Test Equipment
The maintenance of the AADvance controller requires the following test equipment.
Note: All test equipment used should be calibrated and regularly tested for accuracy. Current
measurement devices should be accurate to 0.01mA.
1) Digital voltmeter

DC voltage range 0 to 32V or better.

Resistance resolution 0.01  or better.
2) Current simulation instrument

Output range 4 to 20mA with an accuracy better than 0.05mA.
3) Bench power supply

Output range 0 to 32V dc.

