1-5
Throughput time is the time from input change to output action. Due to the discrete
nature of the scan, the throughput time will vary between one and two scans.
Note: The AADvance application scan time is limited to a minimum of 64ms to allow
all processes to run. Small applications will report a scan time of approximately 57 -
61ms. Large applications may have longer scan times but each scan time will be
consistent to within approximately 5ms.
An example configuration scan time:
T9431 Analogue input simplex modules x 30
T9451 Digital output simplex modules x 18
Total I/O modules
= 48
Estimated scan time = (30 x 1.23ms) + (18 x 1.43ms) + 57.2ms + (48 x 0.09ms)
= 125.1ms
Throughput time:
min = 125.1ms
Avg = 187.6ms
Max = 250.1ms
Environmental Specifications
The following environmental specification defines the minimum recommended
environmental conditions for an AADvance controller installation. Additional
conditions apply to installations in a Hazardous environment.
Table 2: Environmental Specification
Attribute Value
Operating Temperature Range:
For use in Hazardous Environments (UL
Certification):
Processor Modules
I/O Modules and Assemblies
For use in Non-Hazardous Environments
(TUV Certification)
All Modules and Assemblies
–25 °C to 60 °C (–13 °F to 140 °F)
–25 °C to 70 °C (–13 °F to 158 °F)
–25 °C to 70 °C (–13 °F to 158 °F)
Storage and Transport Temperature –40 °C to 70 °C (–40 °F to 158 °F)
Module Surface Temperature (during normal
operation)
43° C (109 °F) ± 2 °C
Humidity
Operating 10% to 95% RH, non-condensing
Storage and Transport 10% to 95% RH, non-condensing
Vibration
